import tkinter as tk

from icmplib import ping

from datetime import datetime

from collections import deque

import matplotlib.pyplot as plt

from matplotlib.backends.backend_tkagg import FigureCanvasTkAgg

import configparser

import matplotlib.dates as mdates

import threading

UPDATETIME = 20

INI_FILE = 'hosts.ini'

COLUMN = 2

GRAHP_WIDTH = 600

GRAHP_HEIGHT = 300

GUI_GEOMETRY = "1220x650"

PING_COUNT = 2

PING_INTERVAL = 2

DATA_LIMIT = 3000

class Host:

def __init__(self, ip, name, width_pixels, height_pixels, log_callback):

self.ip = ip

self.name = name

self.ping_data = deque(maxlen=DATA_LIMIT)

self.time = deque(maxlen=DATA_LIMIT)

self.log_callback = log_callback

dpi = 100

width_inches = width_pixels / dpi

height_inches = height_pixels / dpi

self.fig, self.ax = plt.subplots(figsize=(width_inches, height_inches), dpi=dpi)

self.line, = self.ax.plot([], [], label=f'{ip} {name} ms', color='darkgreen', linestyle='-', linewidth=2)

self.ax.legend()

self.ax.xaxis.set_major_formatter(mdates.DateFormatter('%H:%M'))

self.ax.xaxis.set_major_locator(mdates.MinuteLocator(interval=30))

self.fig.autofmt_xdate()

def ping_host(self, ip, count=PING_COUNT, interval=PING_INTERVAL):

return ping(ip, count=count, interval=interval)

def update_ping(self):

try:

response = self.ping_host(self.ip)

current_time = datetime.now()

self.time.append(current_time)

if response.is_alive:

self.ping_data.append(response.avg_rtt)

else:

self.ping_data.append(0)

self.log_callback(f"{current_time.year}.{current_time.month}.{current_time.day} {current_time.hour}:{current_time.minute} : {self.name} ({self.ip}) недоступен\n")

self.line.set_data(self.time, self.ping_data)

self.ax.relim()

self.ax.autoscale_view()

self.fig.tight_layout()

self.canvas.draw()

except Exception as e:

print(f"Error pinging {self.ip}: {e}")

class App:

def __init__(self, GUI, ini_file):

self.gui = GUI

self.gui.title("Монитор Доступности оборудования")

self.gui.geometry(GUI_GEOMETRY)

self.hosts = self.load_hosts_from_ini(ini_file)

self.log_text = tk.Text(self.gui, height=10, width=80, wrap='none', state='disabled')

self.log_text.grid(row=0, column=0, padx=10, pady=10, sticky="nsew")

self.log_scrollbar = tk.Scrollbar(self.gui, orient="vertical", command=self.log_text.yview)

self.log_scrollbar.grid(row=0, column=1, sticky="ns")

self.log_text['yscrollcommand'] = self.log_scrollbar.set

self.canvas = tk.Canvas(self.gui)

self.scrollbar = tk.Scrollbar(self.gui, orient="vertical", command=self.canvas.yview)

self.scrollable_frame = tk.Frame(self.canvas)

self.scrollable_frame.bind(

"<Configure>",

lambda e: self.canvas.configure(scrollregion=self.canvas.bbox("all"))

)

self.canvas.create_window((0, 0), window=self.scrollable_frame, anchor="nw")

self.canvas.configure(yscrollcommand=self.scrollbar.set)

for i, host in enumerate(self.hosts):

canvas = FigureCanvasTkAgg(host.fig, master=self.scrollable_frame)

canvas.get_tk_widget().grid(row=i//COLUMN, column=i%COLUMN, padx=5, pady=5)

host.canvas = canvas

self.canvas.grid(row=1, column=0, sticky="nsew")

self.scrollbar.grid(row=1, column=1, sticky="ns")

self.gui.grid_rowconfigure(1, weight=1)

self.gui.grid_columnconfigure(0, weight=1)

self.start_ping()

def load_hosts_from_ini(self, ini_file):

config = configparser.ConfigParser()

config.read(ini_file)

return [Host(ip, hostname, width_pixels=GRAHP_WIDTH, height_pixels=GRAHP_HEIGHT, log_callback=self.log_message) for section in config.sections() for hostname, ip in config.items(section)]

def log_message(self, message):

self.log_text.config(state='normal')

self.log_text.insert("1.0", message)

self.log_text.config(state='disabled')

def start_ping(self):

for host in self.hosts:

thread = threading.Thread(target=host.update_ping)

thread.start()

self.gui.after(UPDATETIME * 1000, self.start_ping)

GUI = tk.Tk()

app = App(GUI, INI_FILE)

GUI.mainloop()

https://www.online-python.com/HRuJIQPs3E

формат ини-файла

[DNS]

google1 = 8.8.8.8

google2 = 8.8.4.4

cloudflare1 = 1.1.1.1

Quad9 = 9.9.9.9
