esphome:

name: watering-controller

on_boot:

priority: -10

then:

- switch.turn_off: ball_valve

- switch.turn_off: water_pump

- logger.log: "System started. Safety shutdown initiated."

esp8266:

board: nodemcuv2

logger:

api:

encryption:

key: "6fJmeTpWUwYI1ild+BCDefxR7jzjgrXqRk+wYnQkvtc="

ota:

- platform: esphome

password: "990a849fc897e47a4de21d941c1dc328"

wifi:

ssid: !secret wifi_ssid

password: !secret wifi_password

ap:

ssid: "Kapustini Fallback Hotspot"

password: "88005553535"

captive_portal:

web_server:

port: 80

i2c:

sda: GPIO4

scl: GPIO5

scan: true

time:

- platform: ds1307

id: rtc_time

timezone: "Europe/Moscow"

sensor:

- platform: wifi_signal

name: "WiFi Signal"

id: wifi_signal_sensor

update_interval: 60s

interval:

- interval: 1min

then:

- if:

condition:

and:

- lambda: |-

auto now = id(rtc_time).now();

bool right_time = (now.hour == (int)id(w_hour).state && now.minute == (int)id(w_min).state);

bool day_match = false;

if (now.day_of_week == 1 && id(mon).state) day_match = true;

if (now.day_of_week == 2 && id(tue).state) day_match = true;

if (now.day_of_week == 3 && id(wed).state) day_match = true;

if (now.day_of_week == 4 && id(thu).state) day_match = true;

if (now.day_of_week == 5 && id(fri).state) day_match = true;

if (now.day_of_week == 6 && id(sat).state) day_match = true;

if (now.day_of_week == 7 && id(sun).state) day_match = true;

return right_time && day_match;

then:

- script.execute: watering_script

- if:

condition:

and:

- lambda: |-

auto now = id(rtc_time).now();

int s = id(p_start_hour).state;

int e = id(p_end_hour).state;

if (s <= e) return now.hour >= s && now.hour < e;

return now.hour >= s || now.hour < e;

- binary_sensor.is_off: tank_full

- switch.is_off: pump_error

- switch.is_off: water_pump

then:

- switch.turn_on: water_pump

- if:

condition:

and:

- switch.is_on: water_pump

- not:

lambda: |-

auto now = id(rtc_time).now();

int s = id(p_start_hour).state;

int e = id(p_end_hour).state;

if (s <= e) return now.hour >= s && now.hour < e;

return now.hour >= s || now.hour < e;

then:

- switch.turn_off: water_pump

script:

- id: watering_script

mode: restart

then:

- switch.turn_on: ball_valve

- delay: !lambda "return (int)id(w_duration).state * 60000;"

- switch.turn_off: ball_valve

- id: pump_safety_timeout

mode: restart

then:

- delay: !lambda "return (int)id(max_pump_time).state * 60000;"

- switch.turn_off: water_pump

- switch.turn_on: pump_error

number:

- platform: template

name: "Watering Hour"

id: w_hour

min_value: 0

max_value: 23

step: 1

initial_value: 20

restore_value: yes

optimistic: yes

- platform: template

name: "Watering Minute"

id: w_min

min_value: 0

max_value: 59

step: 1

initial_value: 0

restore_value: yes

optimistic: yes

- platform: template

name: "Watering Duration"

id: w_duration

min_value: 1

max_value: 120

step: 1

initial_value: 15

restore_value: yes

optimistic: yes

- platform: template

name: "Pump Start Hour"

id: p_start_hour

min_value: 0

max_value: 23

step: 1

initial_value: 23

restore_value: yes

optimistic: yes

- platform: template

name: "Pump Stop Hour"

id: p_end_hour

min_value: 0

max_value: 23

step: 1

initial_value: 7

restore_value: yes

optimistic: yes

- platform: template

name: "Pump Max Timeout"

id: max_pump_time

min_value: 1

max_value: 60

step: 1

initial_value: 30

restore_value: yes

optimistic: yes

switch:

- platform: template

name: "Mon"

id: mon

optimistic: yes

restore_mode: RESTORE_DEFAULT_OFF

- platform: template

name: "Tue"

id: tue

optimistic: yes

restore_mode: RESTORE_DEFAULT_OFF

- platform: template

name: "Wed"

id: wed

optimistic: yes

restore_mode: RESTORE_DEFAULT_OFF

- platform: template

name: "Thu"

id: thu

optimistic: yes

restore_mode: RESTORE_DEFAULT_OFF

- platform: template

name: "Fri"

id: fri

optimistic: yes

restore_mode: RESTORE_DEFAULT_OFF

- platform: template

name: "Sat"

id: sat

optimistic: yes

restore_mode: RESTORE_DEFAULT_OFF

- platform: template

name: "Sun"

id: sun

optimistic: yes

restore_mode: RESTORE_DEFAULT_OFF

- platform: template

name: "RESET PUMP ERROR"

id: pump_error

optimistic: yes

icon: "mdi:alert"

restore_mode: RESTORE_DEFAULT_OFF

- platform: gpio

pin: GPIO14

name: "Pump Relay"

id: water_pump

on_turn_on:

- if:

condition:

or:

- switch.is_on: pump_error

- binary_sensor.is_on: tank_full

then:

- switch.turn_off: water_pump

else:

- script.execute: pump_safety_timeout

on_turn_off:

- script.stop: pump_safety_timeout

- platform: gpio

pin: GPIO12

name: "Valve Relay"

id: ball_valve

binary_sensor:

- platform: gpio

pin: {number: GPIO13, mode: INPUT_PULLUP, inverted: true}

name: "Tank Full"

id: tank_full

on_press:

- switch.turn_off: water_pump

- platform: gpio

pin: {number: GPIO2, mode: INPUT_PULLUP, inverted: true}

name: "Overflow Alert"

id: overflow_sensor

on_press:

- switch.turn_off: water_pump

display:

- platform: lcd_pcf8574

address: 0x27

dimensions: 20x4

id: my_display

lambda: |-

int screen = (id(rtc_time).now().timestamp / 10) % 3;

it.strftime(0, 0, "Time: %H:%M:%S", id(rtc_time).now());

it.print(0, 1, "--------------------");

switch (screen) {

case 0:

it.print(0, 2, "PUMP:  ");

it.print(7, 2, id(water_pump).state ? ">> WORKING <<" : "  IDLE  ");

it.print(0, 3, "VALVE: ");

it.print(7, 3, id(ball_valve).state ? ">> OPENING <<" : "  CLOSED  ");

break;

case 1:

it.printf(0, 2, "Set: %02.0f:%02.0f", id(w_hour).state, id(w_min).state);

it.printf(0, 3, "Duration: %.0f min", id(w_duration).state);

break;

case 2:

if (id(pump_error).state) it.print(0, 2, "!!! PUMP ERROR !!!");

else if (id(tank_full).state) it.print(0, 2, "Status: TANK FULL");

else it.print(0, 2, "System: Healthy");

if (id(wifi_signal_sensor).has_state()) {

it.printf(0, 3, "WiFi: %.0f dBm", id(wifi_signal_sensor).state);

}

break;

}
